Ultra-Wide Band Grid Parabolic Dish Cellular WiFi UWB

DISCONTINUED, NO LONGER AVAILABLE. All sold.

Directional dish parabolic grid 32" diameter, single linear polarization, welded aluminum and powder coated in USA. UWB Ultra-wide band design 600 MHz to 6.5 GHz with gain 12dBi at lowest frequency and 26 dBi at highest frequency. Covers all of the L-band, S-band, half C-Band. Heavy duty high winds version of the popular low-cost model. Features extra strong brackets and 1/4" welded aluminum rod forming the dish. Contact us for a detailed data sheet today. Weight of shipping box is only 13 Lbs.

2G, 3G, 4G. Works on all worldwide cellular bands for voice & data:
LTE/CDMA/GSM/UMTS/AWS. 600Mhz band included.All WiFi Bands, and new 5G, 600MHz & 3.5GHz spectrum
ISM 900 &1200Mhz, SDR, plus GPS band Jammer
Military, Government, Homeland Security Bands
Scanner, Narrow Beam Spectrum Search & Energy Harvesting
Sirius-XM (with avail. amplifier) Deep Fringe to Stationary Sats.
Simple install kit with tilt/swivel mast bracket for 1.25 to 2” diameter pipe/mast
Gain & Beamwidth pre-set or Can Optimized at 600-900 or 4000-6500 MHZ. Great for the new Icom IC-905 radio.

Light Weight, Easy To Assemble & Install For Home And Office

Heavy-Duty 1 piece reflector, solid and rigid.

This antenna also works for all popular and expanded WiFi bands including 802.11ah 802.11b 802.11g 802.11n 802.11ax 802.11y 802.11j 802.11a 802.11h 802.11ac 802.11p 802.11be Wifi-6E WiFi 7

Electrical specifications
Frequency range (MHz) 600 - 6500 Covers all of the L-band, S-band, half C-Band
Polarization Vertical or Horizontal
Gain(dBi) 14 Low / 21 Mid / 26 High Bands
Half-power beam width(°) Low Band: 20 Horiz, 23 Vert
Half-power beam width(°) Mid Band: 12 Horiz, 15 Vert
Half-power beam width(°) High Band: 7 Horiz, 9 Vert
Front-to-back ratio(dB) ≥20 AVG
Impedance(Ω) 50
VSWR ≤1.6:1 / 1.4:1 avg
Maximum input power(W) 100
Lightning protection DC Ground

Mechanical specifications
Connector N-female
Dimensions (in / mm) 32.5 / 82cm
Dimensions, boxed (in / mm) 35x35x8.5 / 90x90x21.6
Antenna weight (lb / kg) 5.4 / 2.5 w/bracket
Packing weight (lb / kg) 14 / 6.5
Wind loading area (sqr ft / m)
Rated wind velocity (mph / kph) 150 / 240
Wind Load @ Rated Velo. (lb / kg) 150 / 68
Mounting mast diam. (in / mm) 1.5-2.0 / 40-50
Reflector material Welded Aluminum
Reflector Finish: Electrostatic Powder Coat
Radome material ASA Anti UV
Antenna Reflector color Beige-White
Water resistance IPX Weather rated
Operating temperature(℃ / F) -40 to +60 / -40 to +140
