Technical Specs
Frequency Range (MHz) 698-960 / 1710-2270
Polarization Vertical
Gain (dBi) 9.0
Horizontal Beamwidth (°) 60
Vertical Beamwidth (°) 35
F/B Ratio 20 dB
Impedance (Ω) 50
VSWR 698-960 / 1710-2270 1.5:1 AVG
Max Input Power (W) 50
Connector Your Choice (See Above)
Cable Length 12 Inches
Cable Type RG-58
Dimensions (in) 6.2”x6.7”x2.2”
Antenna Weight Without Brackets 13 Oz
Bracket Kit Weight 4 Oz
Rated Wind Velocity (mph / kph) 90 / 144
Wind Load @ Rated Velo (M / K) 150 / 68
Materials ABS UV Stable, Aluminum
Color White
Operating Temperature (°C / °F) -40 to +55 / -40 to +122
Country of Origin Made In U.S.A. with imported parts
